11.3) L-Type Timing Belts

Minimum Order Quantity (MOQ): 6 units

Common Type H Features:

Pitch: 3/8" (9.525 mm)

Trapezoidal tooth profile, 40°

Tooth height: 1.91 mm

Total belt height: 3.6 mm

Typical materials: Body material: Neoprene rubber or polyurethane; Reinforcement: Fiberglass cord or steel; Tooth facing: Nylon fabric

Standard widths: 1/4", 3/8", 1/2", 3/4", 1"
